The OBH Logo@@Phono Pre-Amplifier




@

¦@’ʏνέŒΙ‚ΝSilverABlack‚Ν“Α’‚Ζ‚Θ‚θ‚ά‚·B


Technical Specifications

THD+noise at 2Vrms output:

1kHz

10kHz

MM (40dB gain)

0.002%

0.003%

MM (50dB gain)

0.007%

0.007%

MC (60dB gain)

0.005%

0.005%

MC (70dB gain)

0.011%

0.012%

Channel Separation

MM (all gains) 1kHz

>70dB

MC (all gains) 1kHz

>70dB

Frequency Response ref RIAA

+/-0.5dB

Signal to Noise ratio (2Vrms output)

MM (40/50dB gain)

76/66dB

MC (60/70dB gain)

77/70dB

Overload Margin

50Hz

1kHz

20kHz

MM (all gains)

21.7dB

21.7dB

21.7dB

MC (all gains)

20.7dB

20.7dB

20.7dB

Maximum Output level

6.1Vrms

6.1Vrms

6.1Vrms

Output Impedance

100 Ohms

Gain

MM

40dB

50dB



MC

60dB

70dB

80dB

Matching

MM

100pF or 200pF plus 47k Ohms

MC

100pF or 1100pF plus 100 Ohms or 510 Ohms

Size: Width x Height x Depth

100 x 63 x 150mm

Weight:

1.5kgs inc OBH-Uni power adapter

Power consumption

24V @ <150mA (<3.6W)

Mains voltage requirements

100V to 250V AC 50/60Hz

Connections to the mains

4 types of mains clip-on plug are supplied as standard UK,North America, Europe and Australasia
